Specification | Unit | Numerical Value |
| Master Cylinder Nominal Pressure | KN | 1000 |
| Master Cylinder Stroke | mm | 750 |
| Maximum Closed Height | mm | 1300 |
| Assembly Mold Height | mm | 570 |
| Booster Cylinder Stroke | mm | 350 |
| Slide Stroke | mm | 250 |
| Injection Cylinder Stroke | L | 5.3 |
| Injection Cylinder Liquid Maximum Pressure | MPa | 50 |
| Injection Cylinder Injection Speed | mL/s | 600 |
| Active Beam Speed-Fast Down | mm/s | 700 |
| Active Beam Speed-Quick Clamping | mm/s | 60 |
| Active Beam Speed-Fast Return | mm/s | 600 |
| Mobile Workbench Size-Left and Right | mm | 550 |
| Mobile Workbench Size-Before and After | mm | 450 |
| Replenishment System Maximum Pressure | MPa | 4 |
| Motor Power | KW | 22+3 |
| Barrel of Hydraulic Oil | L | 190 |
| Fuel Tank Capacity | L | 630 |
